FEATURES

· RF wireless communication function

· LCD and high brightness LED display the slope at same time

· 240º angle range receivable

· Receiving signal position LCD display

· LED indicates on-grade information clearly

· Sound indicates the exact on-grade position

· Low voltage power-off automatically

· Vibration-proof, shockproof and rainproof

· Additional fixing clamp holder

Communication function

RF wireless communication

Location information output(Output to the controller)

N

Display

IP class

LED and LCD display

IP 66

Detecting radius

200m

Receiving angle

240°

Measuring accuracy

±5mm

Detecting window

120mm

Working temperature

-10℃～+50℃

Power supply

4*AA battery

Size

170*115*42mm

Weight

0.7kg
